1971-1972 Triumph 120 OIF Rear Fender Unpainted 83-3566
This mudguard is the correct fitment for the 1971 and 1972 Triumph 650 models with painted fenders. Can also be fitted to the BSA A65 and A70 models from 1971 and 1972, although they were originally specified with chrome plated fenders.
The genuine Speedwell mudguard is made in the UK and features the correct ‘D’ shaped profile and indents for the wiring harness and battery carrier clearance. Supplied undrilled and unpainted. These fenders are handmade individually and require careful prep work.
The Triumph 120 OIF rear fender serves as the mount for the tail lamp assembly and is supported by a cross bridge between the top shock absorber mounts and a bracket welded to the rear frame loop.
The mudguard is loosely fitted to the mounting points to check alignment and establish the position for the drilled holes. A stepped drill bit is useful for drilling through the heavy gauge steel.
The product images shown are for illustrative purposes only and may not be an exact representation of the product received. Manufacturers occasionally make minor cosmetic changes to items, such as color, finish, label, or design. These changes do not impact the item’s function or compatibility. Please contact us if you have specific concerns regarding appearance.
